PE-03 Phaco Emulsifier

The PE-03 is a microprocessor-controlled phacoemulsifier with 40 kHz ultrasonic emulsification. It offers four emulsification modes (continuous, pulse, linear and burst), with digital frequency tracing for smooth control of the process. A large TFT touchscreen gives access to up to 10 preset parameter sets, so the surgeon can save settings for different procedures.

The system includes built-in vitrectomy with an air-pump cutter and bipolar cautery, so one unit covers several steps of anterior segment surgery. An auto test checks tubing and handpieces for blockage or leakage before use. A peristaltic pump gives control over aspiration flow, which helps reduce anterior chamber shallowing during I/A.

For professional use by qualified ophthalmic surgeons.

Key features

• 40 kHz ultrasonic emulsification
• Four modes: continuous, pulse (1 to 99 Hz), linear (foot-switch controlled) and burst
• Peristaltic pump with aspiration flow control
• Built-in vitrectomy (VIT) with air-pump cutter
• Bipolar cautery, maximum 10 W
• Up to 10 preset parameter sets
• Auto test of tubing and handpieces for blockage or leakage
• Large TFT touchscreen with intelligent voice reminder

Specifications

Standard configuration

• Phaco emulsifier × 1
• Foot switch × 1
• Reusable tubing kit × 1
• U/S handpiece × 1
• I/A handpiece × 1
• U/S tip (30°) × 1
• Tip wrench × 1
• Test chamber × 1
• VIT tip × 1
• Irrigation sleeve × 2
• Irrigation sleeve (VIT) × 1
• Cautery forceps with cable × 1
